Features:
- IP66 Rated ( When closed) resistant to dust and a flow of water up to 1kg/cm2 in any direction
- IK08 Protection grade when closed - 1500kg maximium weight limit
- Maximum weight per area: 12kg/cm2
- Required opening dimensions - Screed back box 115mm x 115mm x 81mm, Raised floor back box 125mm x 125mm
- Joiner clip availavle to join 2 screed back boxes - Code KFA1002
- Levelling accessory - KFA1003 - assists in levelling the back box
- Replacement lid KFS1001/72 and sandwich gasket KFS1002 and lid gasket KFS1003 are available to order
Description:
NEW SIMONBOX IP66 rated top section. The brushed stainless steel covered top section features a manual twist locking mechanism. The top section requires a back box. Screed type box ref: KGT100/72. Raised floor back box:KGT100RF/72. Internally the outlet is supplied with a 13amp unswitched UK socket and a blanked 22.5mm x 45mm data space. This space can be fitted with a range of data socket options. ( These may be ordered seperately)
When closed the outlet achieves an IP66 rating. When open the unit is IP20 rated. The screed floor outlet sits flush with the surrounding floor finish. The raised floor version features a matching metal supporting surround trim. Internally the outlet is slightly sloped directing any liquid that has entred to outlet towards a weep hole which is,in turn, is positioned over a collection resevoir within the back box. This resevoir forms part of the back boxes drainage system.
